CONTROL or
INDICATOR
FUNCTION
POWER Fault indicator that lights if a momentary power failure
occurs. Momentarily shutting down system power clears
this condition.
PRINT Obtain a printout of the current test at any time, or a
printout of the last test when no test is running.
IEEE Status indicator that is lit when an IEEE-488 option is set
to receive keyboard commands from an external
computer. The indicator does not light if the IEEE option
is not installed.
S1 Enables or disables system options, as follows:
(a)System reset option - clearing of nonvolatile
memory. Press S1, then 0 and ENTER on keypad.
This sequence clears the nonvolatile memory,
setting all variables to a default state, and there-
by resetting the system to a known condition.
Also, any previously stored data will be lost. The
Main Panel Display will show “LOSS” after this type
of reset key sequence is entered.
(b)System reset option - no clearing of nonvolatile
memory. Press S1, then 1 and ENTER on the key-
pad. This sequence is a“warm restart” of the
system which is used to to reset certain fault
conditions, without resetting nonvolatile memory to
the default state; that is, all previously entered
parameters will remain in storage. An exception is
when this sequence is used to enable a change in
system operating units.
Table 4-1. Main Panel Functions (continued)
Function Of Controls M10-94400-1
4-8
To Next Page
