Electronic Parts
Service Parts Lists
CUSA EXcel Ultrasonic Surgical Aspirator System Service Manual 14-7
Connectors
Table 14-11.
Ultrasonics board parts—connectors
Reference
Designator Description
Integra
Part Number
J6 Connector PCB, 2 CKT, 0.256 in. centers 208160052
J4 Connector PCB, 3 CKT, 0.256 in. centers 208160053
J15 Connector PCB, 4 CKT, 0.256 in. centers 208160054
J3 Connector PCB, 5 CKT, 0.256 in. centers 208160055
J1 Connector PCB, 10 CKT, 0.256 in. centers 208160060
J14 Connector PCB, 6 CKT, 0.100 in. centers 208200321
J12 Connector PCB, 40 CKT Dual Row, Ribbon 208200323
J7 Connector PCB, 12 PIN, Dual Row, 0.100 in.
centers
208200382
J9 Connector PCB, 20 PIN, Dual Row, Ribbon 208200383
J5, 10, 11, 18 Header, 2 PIN, 0.100 in. centers, Lock 208200389
J16, 17, 19 Header, 4 PIN, 0.100 in. centers, Lock 208200390
J8, 13 Header, 2 PIN, 0.295 in. centers, Lock 208200391
J2 Connector CIR Receptacle, 7 CKT 208300818
