Miscellaneous Spare Parts
14-8 CUSA EXcel Ultrasonic Surgical Aspirator System Service Manual
Miscellaneous
Table 14-12.
Ultrasonics board parts—
miscellaneous
Miscellaneous Spare Parts
Reference
Designator Description
Integra
Part Number
All TPs Test Point 208200284
6 Contact Socket CPC PC MO 208200378
All JMPs Jumper, 0.100 in. center, Wire 208400117
5 Socket FET Single Pin 208500106
7 Nut Plate, Footswitch Connector 223301195
2 Heatsink, T0-220 Pkg. 223400757
4 Nut Hex 4-40 STL NKL PLD 224011023
K1 Relay Reed, Ultramini, SPST 230017010
3 Screw, Pan Hd, Phil 4-40 X 1/2 237100680
SW1, 2, 3, 4 Dip Switch 243080015
U27 TRANSF, 24 V dc to 15 V dc Converter 251200086
All DFs Filter, EMI, 1MHz FC, 3 Pins 251400011
Reference
Designator Description
Integra
Part Number
CUSA EXcel Service Transportation Case 4103002IE
