Symbols on the Control Panel
4-16 CUSA EXcel Ultrasonic Surgical Aspirator System Service Manual
Symbols on the Control Panel
Some symbols appear on the control panel. The following list shows each symbol
and its meaning.
Figure 4-8.
Control panel symbols
Vibration
amplitude out of range
Footswitch failure or footswitch not connected
Handpiece failure or handpiece not connected
Cooling water:
Alert (red, left side of the control panel)—failure
Wait (amber, right side of the control panel)—system is circulating cooling water
through the handpiece or draining the handpiece
On/selected
Laparoscopic mode
