Preparing the CUSA EXcel Console for Use
Unpacking and Installing
the CUSA EXcel Surgical
CUSA EXcel Ultrasonic Surgical Aspirator System Service Manual 3-9
Replacing the Power Connector
If your facility’s power receptacles are not compatible with the standard connector
supplied on the CUSA EXcel system, install a different power connector
according to your institution’s policy.
Tools needed:
Slotted blade screwdriver
Procedure:
1. Remove the connector provided with the unit.
2. Attach the new connector, using the following chart:
Table 3-1.
Wire colors
Ensure that all electrical
installations comply with local
codes and regulatory
requirements.
The power connector meets all requirements for safe grounding. Do not defeat its
purpose by using extension cords or three-prong-to-two-prong adapters.
Periodically check the power cord for damaged insulation or connectors. Always
grasp cords by the connector; do not pull on the cord to remove the connector
from the wall receptacle.
If required by local regulations, connect an equipotential grounding cable to the
equipotential grounding lug on the rear of the CUSA EXcel console.
Wire Color Prong
green with yellow stripe safety ground
brown line/hot
light blue neutral
Notice
To avoid product damage, be sure to insert fuses that are appropriate to the power supply:
• 95 to 120 V, T10A, Time Delay (default)
• 220 to 240 V, T5A, Time Delay
