Unpacking the CUSA EXcel System
Unpacking and Installing
the CUSA EXcel Surgical
CUSA EXcel Ultrasonic Surgical Aspirator System Service Manual 3-3
3. Cut and remove the
horizontal bands on the
crate.
Note: Save the box edge
protectors for use when
shipping the system.
4. Remove the three plastic clips that hold the crate closed. (If the clip is
especially tight, you may need to use pliers for this step.) Refer to the
following figure.
a. Inside the clip, grasp the two horizontal bars near the locking retainer (on
the right side of the clip).
b. Squeeze the bars toward each other to release them from the locking
retainer.
c. Pull the bars toward you. They should swing outward.
d. Pull the tab at the bottom of the clip to remove the clip from the carton.
