Intel® Server System M50CYP1UR Family System Integration and Service Guide
69
6.1.2 System Cover Installation
Figure 76. System Cover Installation
For each top cover panel:
1. Carefully align and set the top cover panel on top of the chassis. Then, slide it inwards until it locks into
place (see Letter A).
Shipping Note: When transporting the server system, Intel recommends installing the four top cover screws
before shipping.
6.2 System Fan Replacement
Individual fans used in the Intel® Server System M50CYP1UR family are hot-swappable.
Required Tools and Supplies
• Anti-static wrist strap and conductive workbench pad (recommended)
Note: Only individual fans can be removed or installed on the Intel® Server System M50CYP1UR family. The
entire system fan assembly cannot be removed from the chassis.
Caution: To minimize possible performance degradation and other thermal related issues, system fan
replacement while the system is operational should be performed as quickly as possible.
System fans operate at very high speeds. Keep all tools and fingers away from all operational system fans
when swapping out a defective fan.
Components within an operational system can get very hot. Avoid touching any components within the
system while swapping out a defective system fan.
