Intel
®
Server Board S2600CP and Server System P4000CP TPS
Intel® Server Board S2600CP Connector/Header Locations and Pin-outs
Revision 1.1
Intel order number G26942-003
91
7.3.7 HSBP_I2C Header
Table 38. HSBP_I2C Header Pin-out
Pin Signal Name
1 SMB_HSBP_3V3STBY_DATA
2 GND
3 SMB_HSBP_3V3STBY_CLK
7.3.8 HDD LED Header
The server board includes a 2-pin hard drive activity LED header used with some SAS/SATA
controller add-in cards. The header has the following pin-out.
Table 39. HDD LED Header Pin-out
Pin Signal Name
Pin
Signal Name
1 LED_HDD_ACT_N 2 NA
7.3.9 Internal Type- A USB Connector
The server board includes one internal Type-A USB connector. The following table provides the
pin-out for this connector.
Table 40. Type-A USB Connector Pin-out
Pin Signal Name Pin Signal Name
1 P5V 2 USB2_P2_F_DN
3 USB2_P2_F_DP 4 GND
7.3.10 Internal eUSB SSD Header
The server board includes one 10-pin internal eUSB header with an intended usage of
supporting USB SSD devices. The following table provides the pin-out for this connector.
Table 41. eUSB SSD Header Pin-out
Pin Signal Name Pin Signal Name
1 5V 2 NC
3 USB2_PCH_P12_DN 4 NC
5 USB2_PCH_P12_DP 6 NC
7 GND 8 NC
9 Key 10 LED_HDD_ACT_ZEPHER_N
7.4 Management and Security Connectors
7.4.1 RMM4_Lite Connector
A 7-pin Intel
®
RMM4 Lite connector is included on the server board to support the optional Intel
®
Remote Management Module 4. There is no support for third-party management cards on this
server board.
