Intel®

Server Board S2600CP Overview Intel

Server Board S2600CP and Server System P4000CP TPS

Revision 1.1

Intel order number G26942-003

2.2.3 Server Board Rear I/O Layout

The following drawing shows the layout of the rear I/O components for the server boards.

Callout Description Callout Description

A Serial Port A E NIC Port 3 (top) and 4 (bottom)

B Video F Diagnostics LED’s

NIC Port 1, USB Port 0 (top) and 1

(bottom)

G ID LED

NIC Port 2, USB Port 2 (top) and 3

(bottom)

H System Status LED

Figure 13. Rear I/O Layout of Intel

Server Board S2600CP4
