Intel® Server Board S2600CP Overview Intel
®
Server Board S2600CP and Server System P4000CP TPS
4 Revision 1.1
Intel order number G26942-003
Feature Description
Hard Drive and Optical
Drive Support
 Intel
®
Server Board S2600CP2/S2600CP2J/S2600CP4: Two SATA connectors at 6
Gbps (white connectors) and four SATA connectors at 3 Gbps (black connectors). The
6 Gbps connectors are recommended connectors for ODDs.
 Intel
®
Server Board S2600CP2/S2600CP4: Up to eight SATA/SAS connectors at 3
Gbps with optional Intel
®
C600 RAID Upgrade Keys
RAID Support  Intel RSTe SW RAID 0/1/10/5
 LSI SW RAID 0/1/10
External I/O Connectors  One DB-15 video connector
 One DB9 serial port A connection
 Support two or four 10/100/1000Mb NIC
 Four USB 2.0 ports
Internal I/O
Connectors/Headers
 One 2x5 pin connector providing front panel support for two USB ports
 One internal Type-A USB 2.0 port
 One internal USB port to support low profile eUSB SSD
 One DH-10 serial Port B connector
 One combined header consists of a 24-pin SSI-EEB compliant front panel header and
a 4-pin header for optional NIC3/4 LED
 One 1x7pin header for optional Intel
®
Local Control Panel support
Video Support Integrated Matrox* G200 2D Video Graphics controller
LAN Intel
®
Server Board S2600CP2/S2600CP2J : Two Gigabit network through Intel
®
I350
10/100/1000 integrated MAC and PHY controller
Intel
®
Server Board S2600CP4: Four Gigabit network through Intel
®
I350 10/100/1000
integrated MAC and PHY controller
Server Management  Onboard ServerEngines* LLC Pilot III* Controller
 Support for Intel
®
Remote Management Module 4 solutions
 Intel
®
Light-Guided Diagnostics on field replaceable units
 Support for Intel
®
System Management Software
 Support for Intel
®
Intelligent Power Node Manager (Need PMBus-compliant power
supply)
BIOS Flash  Winbond* W25Q64BV
Form Factor  SSI EEB (12”x13”)
Compatible Intel
®
Server
Chassis
Inte
l
®
Server Chassis P4000M chassis

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
