4.5.1.2 Wake-up Control
The super I/O contains functionality that allows various events to power on and power off the
system.
4.5.2 Graphics Controller and Video Support
The integrated graphics controller provides support for the following features as implemented on
the server board:
Integrated Graphics Core with 2D Hardware accelerator
DDR-3 memory interface with 16 MB of memory allocated and reported for graphics
memory
High speed Integrated 24-bit RAMDAC
Single lane PCI-Express host interface running at Gen 1 speed
The integrated video controller supports all standard IBM VGA modes. The following table
shows the 2D modes supported for both CRT and LCD:
Table 10. Video Modes
2D Mode 2D Video Mode Support
8 bpp
16 bpp
24 bpp
32 bpp
640x480
X
X X X
800x600
X X X X
1024x768
X X X X
1152x864
X X X X
1280x1024
X X X X
1600x1200**
X X
** Video resolutions at 1600x1200 and higher are only supported through the
external video connector located on the rear I/O section of the server board.
Utilizing the optional front panel video connector may result in lower video
resolutions.
The BIOS supports dual-video mode when an add-in video card is installed.
In the single mode (dual monitor video = disabled), the on-board video controller is
disabled when an add-in video card is detected.
In the dual mode (on-board video = enabled, dual monitor video = enabled), the on-board video
controller is enabled and is the primary video device. The add-in video card is allocated
resources and is considered the secondary video device. The BIOS Setup utility provides
options to configure the feature as follows:
Table 11. Video mode
On-board Video
Enabled
Disabled
Dual Monitor Video
Enabled
Disabled
Shaded if on-board video is set to "Disabled"
