Server Board S2600CP and Server System P4000CP TPS Intel
®
Server System P4000CP Power System Options
Revision 1.1
Intel order number G26942-003
153
Pin Signal 18 AWG color Pin Signal 18 AWG Color
3 COM Black 7 +12V1 White
4 COM Black 8 +12V1 White
13.4.2.2.3 Processor#1 Power Connector (P3)
 Connector housing: 8-Pin Molex* 39-01-2080 or equivalent
 Contact: Molex* Mini-Fit, HCS Plus, Female, Crimp 44476 or equivalent
Table 113. P1 Processor Power Connector
Pin Signal 18 AWG color Pin Signal 18 AWG Color
1 COM Black 5 +12V1 Brown
2 COM Black 6 +12V1 Brown
3 COM Black 7 +12V1 Brown
4 COM Black 8 +12V1 Brown
13.4.2.2.4 Power Signal Connector (P4)
 Connector housing: 5-pin Molex* 50-57-9405 or equivalent
 Contacts: Molex* 16-02-0087 or equivalent
Table 114. Power Signal Connector
Pin Signal 24 AWG Color
1 I2C Clock White
2 I2C Data Yellow
3 SMBAlert# Red
4 COM Black
5 3.3RS Orange
13.4.2.2.5 2x2 12V connector (P12-P16)
Connector header: Foxconn p/n HM3502E-P1 or equivalent
Table 115. P12 12V connectors
Pin Signal 18 AWG color Pin Signal 18 AWG Color
1 COM Black 5 +12V1 Yellow
2 COM Black 6 +12V1 Yellow
Table 116. P13 - P16 12V connectors
Pin Signal 18 AWG color Pin Signal 18 AWG Color
1 COM Black 5 +12V2 Yellow
2 COM Black 6 +12V2 Yellow
13.4.2.2.6 Legacy 1x4 Peripheral Power Connectors (P7, P8, P9, P10)
 Connector housing: Molex* 0015-24-4048 or equivalent;
 Contact: Molex* 0002-08-1201 or equivalent

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
