Chassis-specific sensors
Table 144. Chassis-specific Sensors
Intel
®
Server Chassis Fan Tachometer
sensors
Fan Presence sensors Physical security
(Chassis intrusion)
Sensor
FP interrupt (FP NMI Diag
Int)
P4208XXM/
P4308XXM (Fixed
fans, fixed or
redundant PSUs)
System Fan 1(30h)
NA Physical Scrty (04h) FP NMI Diag Int (05h)
System Fan 2(31h)
NA NA NA
P4208XXM/
P4308XXM/
P4216XXM
(Redundant fans,
redundant PSUs)
System Fan 1 (30h) Fan 1 Present (40h)
Physical Scrty (04h) FP NMI Diag Int (05h)
System Fan 2 (31h) Fan 2 Present (41h)
NA NA
System Fan 3 (32h) Fan 3 Present (42h)
NA NA
System Fan 4 (33h) Fan 4 Present (43h)
NA NA
System Fan 5 (34h) Fan 5 Present (44h)
NA NA
Hot-plug fan support
Supported on
 Intel
®
Server Chassis P4208XXM (Redundant fans, redundant PSUs)
 Intel
®
Server Chassis P4308XXM (Redundant fans, redundant PSUs)
 Intel
®
Server Chassis P4216XXM (Redundant fans, redundant PSUs)
Fan redundancy support
Supported on
 Intel
®
Server Chassis P4208XXM (Redundant fans, redundant PSUs)
 Intel
®
Server Chassis P4308XXM (Redundant fans, redundant PSUs)
 Intel
®
Server Chassis P4216XXM (Redundant fans, redundant PSUs)
Fan domain definition
Table 145. Fan Domain Definition
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
P4208XXM/
P4308XXM
(Fixed fans,
fixed or
redundant
PSUs)
0
 Memory channels C and D(B1h)
 Memory channels E and F(B2h)
 BMC Temp(23h)
 Memory VR(25h)
 Baseboard NIC(2Fh)
 Server South Bridge(22h)
 Hot-swap backplane 1(29h)
 Hot-swap backplane 2(2Ah)
System Fan 1(30h)
1
 P1 Therm Margin(74h)
 P2 Therm Margin(75h)
 Memory channels A and B(B0h)
 Memory channels C and D(B1h)
System Fan 2(31h)

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
