Server System P4000CP Power System Options Intel
®
Server Board S2600CP and Server System P4000CP TPS
Revision 1.1
Intel order number G26942-003
126
Pin Signal 18 awg color Pin Signal 18 awg color
2 COM Black 6 +12V1 Yellow
3 COM Black 7 +12V1 Yellow
4 COM Black 8 +12V1 Yellow
13.2.1.1.3 Processor/Memory Power Connector (P3)
 Connector housing: 8- Pin Molex* 39-01-2085 (94V2) or equivalent
 Contact: Molex*, Mini-Fit Jr, HCS, 44476-1111 or equivalent
Table 66. P3 Processor#1 Power Connector
Pin Signal 18 awg color Pin Signal 18 awg color
1 COM Black 5 +12V2 Yellow
2 COM Black 6 +12V2 Yellow
3 COM Black 7 +12V2 Yellow
4 COM Black 8 +12V2 Yellow
13.2.1.1.4 Peripheral Power Connectors (P6,7,8,9,10)
 Connector housing: Amp 1-480424-0 or equivalent
 Contact: Amp 61314-1 contact or equivalent
Table 67. Peripheral Power Connectors
Pin Signal 18 AWG Color
1 +12V3 Yellow/Black
2 COM Black
3 COM Black
4 +5 VDC Red
13.2.1.1.5 SATA Hard Drive Power Connectors (P4, P5)
 Connector housing: JWT A3811H00-5P (94V2) or equivalent
 Contact: JWT A3811TOP-0D or equivalent
Table 68. SATA Power Connector
Pin Signal 18 AWG Color
1 +3.3V Orange
2 COM Black
3 +5VDC Red
4 COM Black
5 +12V2 Yellow/Black
13.2.2 Temperature Requirements
The power supply shall operate within all specified limits over the T
op
temperature range.

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
