Intel
®
Server Board S2600CP and Server System P4000CP TPS Design and Environmental Specifications
Revision 1.1
Intel order number G26942-003
165
15.2 Intel
®
Server System P4000CP Environmental Limits
The following table defines the Intel
®
Server System P4000CP system level operating and non-
operating environmental limits. Operation of the Intel
®
Server System P4000CP at conditions
beyond those shown in the following table may cause permanent damage to the system.
Exposure to absolute maximum rating conditions for extended periods may affect system
reliability.
Table 139. System Environmental Limits Summary
Parameter Limits
Temperature
Operating 10º C to 35º C (50º F to 95º F) with the maximum rate of change not to exceed
10°C per hour
Non-Operating -40º C to 70º C (-40º F to 158º F)
Humidity
Non-Operating 50% to 90%, non-condensing with a maximum wet bulb of 28° C (at temperatures
from 25° C to 35° C)
Shock
Operating Half sine, 2g, 11 mSec
Unpackaged Trapezoidal, 25 g, velocity change is based on packaged weight
Packaged Product Weight: ≥ 40 to < 80
Non-palletized Free Fall Height = 18 inches
Palletized (single product) Free Fall Height = NA
Vibration
Unpackaged 5 Hz to 500 Hz 2.20 g RMS random
Packaged 5 Hz to 500 Hz 1.09 g RMS random
AC-DC
Voltage 90 Hz to 132 V and 180 V to 264 V
Frequency 47 Hz to 63 Hz
Source Interrupt No loss of data for power line drop-out of 12 mSec
Surge Non-
operating and
operating
Unidirectional
Line to earth
Only
AC Leads 2.0 kV
I/O Leads 1.0 kV
DC Leads 0.5 kV
ESD
Air Discharged 12.0 kV
Contact
Discharge
8.0 kV
Acoustics
Sound
Power
Measured
Power in Watts <300 W ≥300 W ≥600 W ≥1000 W
Servers/Rack
Mount BA
7.0 7.0 7.0 7.0
15.3 MTBF
The following is the calculated Mean Time Between Failures (MTBF) 30C (ambient air). These
values are derived using a historical failure rate and multiplied by factors for application,
