Intel® Server Board S2600CP and Intel® Server System P4000CP Platform Management
Intel® Server Board S2600CP and Server System P4000CP TPS
Revision 1.1
Intel order number G26942-003
64
Code Reason for Beep Associated Sensors
1-5-1-4 The system does not power on or
unexpectedly powers off and a power
supply unit (PSU) is present that is an
incompatible model with one or more
other PSUs in the system
PS Status
6.2.5 Diagnostic Interrupt (NMI) Button
The BMC generates an NMI pulse under certain conditions. The BMC-generated NMI pulse
duration is at least 30 ms. Once an NMI has been generated by the BMC, the BMC does not
generate another NMI until the system has been reset or powered down.
The following actions cause the BMC to generate an NMI pulse:
a. Receiving a Chassis Control command to pulse the diagnostic interrupt. This
command does not cause an event to be logged in the SEL.
b. Watchdog timer pre-timeout expiration with NMI/diagnostic interrupt pre-
timeout action enabled.
Table 16 shows behavior regarding NMI signal generation and event logging by the BMC.
Table 16. NMI Signal Generation and Event Logging
Causal Event NMI
Signal Generation
Front Panel Diag Interrupt Sensor Event Logging
Support
Chassis Control command (pulse diagnostic
interrupt)
X –
Front panel diagnostic interrupt button pressed X X
Watchdog Timer pre-timeout expiration with
NMI/diagnostic interrupt action
X X
6.2.6 BMC Watchdog
The BMC FW is increasingly called upon to perform system functions that are time-critical in
that failure to provide these functions in a timely manner can result in system or component
damage. Intel
®
Server Platforms introduce a BMC watchdog feature to provide a safe-guard
against this scenario by providing an automatic recovery mechanism. It also can provide
automatic recovery of functionality that has failed due to a fatal FW defect triggered by a rare
sequence of events or a BMC hang due to some type of HW glitch (for example, power).
This feature is comprised of a set of capabilities whose purpose is to detect misbehaving
subsections of BMC firmware, the BMC CPU itself, or HW subsystems of the BMC component,
and to take appropriate action to restore proper operation. The action taken is dependent on the
nature of the detected failure and may result in a restart of the BMC CPU, one or more BMC
HW subsystems, or a restart of malfunctioning FW subsystems.
The BMC watchdog feature will only allow up to three resets of the BMC CPU (such as HW
reset) or entire FW stack (such as a SW reset) before giving up and remaining in the uBOOT
code. This count is cleared upon cycling of power to the BMC or upon continuous operation of
the BMC without a watchdog-generated reset occurring for a period of > 30 minutes. The BMC
To Next Page
