Intel S2600CP Family User Manual

Intel
®
Server Board S2600CP and Server System P4000CP TPS Intel® Server Board S2600CP Overview
Revision 1.1 3
Intel order number G26942-003
2. Intel
®
Server Board S2600CP Overview
The Intel
®
Server Board S2600CP is a monolithic printed circuit board (PCBs) with features
designed to support the pedestal server markets. This server board is designed to support the
Intel
®
Xeon
®
processor E5-2600 product family. Previous generation Intel
®
Xeon
®
processors are
not supported.
The Intel
®
Server Board S2600CP family includes different board configurations:
 Intel
®
Server Board S2600CP2: dual NIC ports
 Intel
®
Server Board S2600CP4: quad NIC ports
 Intel
®
Server Board S2600CP2J: dual NIC ports and no SCU ports
2.1 Intel
®
Server Board S2600CP Feature Set
Table 1. Intel
®
Server Board S2600CP Feature Set
Feature Description
Processors  Support for one or two Intel
®
Xeon
®
E5-2600 Processor(s)
 8 GT/s Intel
®
Quick Path Interconnect (Intel
®
QPI)
 LGA 2011 Socket
 Thermal Design Power up to 135-W
Memory  Eight memory channels (four channels for each processor socket)
 Channels A, B, C, D, E, F, G and H
 Support for 800/1066/1333/1600 MHz/s Registered DDR3 Memory (RDIMM),
Unbuffered DDR3 memory ((UDIMM) and Load Reduced DDR3 memory (LRDIMM).
 DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Refer to chapter 4.2.2 for detail information for memory support.
 Chipset Intel
®
C600 -A chipset with support for Intel
®
C600 RAID Upgrade Keys
Cooling Fan Support  Two processor fans (4-pin headers)
 Six front system fans (6-pin headers)
 One rear system fan (4-pin header)
Add-in Card Slots  Support up to six expansion slots
 From first processor:
o Slot 1: PCIe Gen III x4/x8 electrical with x8 physical connector
o Slot 2: PCIe Gen III x8 electrical with x8 physical connector
o Slot 3: PCIe Gen III x8 electrical with x8 open-ended physical connector
o Slot 4: PCIe Gen III x8 electrical with x8 physical connector
o Slot 6: PCIe Gen III x8 electrical with x16 connector, support riser card.
 From second processor:
o Slot 5: PCIe Gen III x8 electrical with x8 open-ended physical connector. PCIe slot 5
is functional only when the second processor is installed.

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
