69
c. Rearm type: Auto
The following sensor-specific offsets are supported.
Table 19. Supported Power Supply Status Sensor Offsets
Offset Description Event Logging
00h Presence detected – Asserted if power supply module is present. Events
are only logged for power supply presence upon changes in the presence
state after AC power is applied (no events logged for initial state).
Assertion and
Deassertion
01h Power supply failure detected – Asserted if power supply module has failed.
The following codes for failure modes are put into the SEL Event Data 2
byte:
 01h - Output voltage fault
 02h - Output power fault
 03h - Output over-current fault
 04h - Over-temperature fault
 05h – Fan fault
The SEL Event Data 3 byte will have the contents of the associated PMBus
Status register to allow for showing multiple conditions for the event. For
example, Data 3 will have the contents of the VOLTAGE_STATUS register
at the time an Output Voltage fault was detected. Refer to the PMBus
Specification for details on specific resister contents
Assertion and
Deassertion
02h Predictive failure – Asserted if some condition, such as failing fan, has been
detected that is likely to lead to a power supply module failure.
The following codes for warning modes are put into the SEL Event Data 2
byte:
 01h - Output voltage warning
 02h - Output power warning
 03h - Output over-current warning
 04h - Over-temperature warning
 05h - Fan warning
 06h - Under-voltage warning
 07h - Input over-current warning
 08h - Input over-power warning
The SEL Event Data 3 byte will have the contents of the associated PMBus
Status register to allow for showing multiple conditions for the event. For
example, Data 3 will have the contents of the VOLTAGE_STATUS register
at the time an Output Voltage Warning was detected. Refer to the PMBus
Specification for details on specific resister contents.
Assertion and
Deassertion
03h Power supply AC lost – Asserted if there is no AC power input to power
supply module.
Assertion and
Deassertion

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
