Server Board S2600CP and Server System P4000CP TPS Intel® Server Board S2600CP Functional Architecture
Revision 1.1
Intel order number G26942-003
29
Table 3. Mixed Processor Configurations
Error Severity System Action
Processor family not
Identical
Fatal The BIOS detects the error condition and responds as follows:
 Logs the POST Error Code into the System Event Log (SEL).
 Alerts the BMC to set the System Status LED to steady Amber.
 Displays “0194: Processor family mismatch detected”
message in the Error Manager.
 Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
Processor model not
Identical
Fatal The BIOS detects the error condition and responds as follows:
 Logs the POST Error Code into the System Event Log (SEL).
 Alerts the BMC to set the System Status LED to steady Amber.
 Displays “0196: Processor model mismatch detected”
message in the Error Manager.
 Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
Processor cores/threads not
identical
Fatal The BIOS detects the error condition and responds as follows:
 Logs the POST Error Code into the SEL.
 Alerts the BMC to set the System Status LED to steady Amber.
 Displays “0191: Processor core/thread count mismatch
detected” message in the Error Manager.
 Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
Processor cache not
identical
Fatal The BIOS detects the error condition and responds as follows:
 Logs the POST Error Code into the SEL.
 Alerts the BMC to set the System Status LED to steady Amber.
 Displays “0192: Processor cache size mismatch detected
message in the Error Manager.
 Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.
Processor frequency (speed)
not identical
Fatal The BIOS detects the processor frequency difference, and responds
as follows:
 Adjusts all processor frequencies to the highest common
frequency.
 No error is generated – this is not an error condition.
 Continues to boot the system successfully.
If the frequencies for all processors cannot be adjusted to be the
same, then this is
an error, and the BIOS responds as follows:
 Logs the POST Error Code into the SEL.
 Alerts the BMC to set the System Status LED to steady Amber.
 Does not disable the processor.
 Displays “0197: Processor speeds unable to synchronize”
message in the Error Manager.
 Takes Fatal Error action (see above) and will not boot until the
fault condition is remedied.

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
