Server Board S2600CP and Server System P4000CP TPS

Intel® Server Board S2600CP Connector/Header Locations and Pin-outs

Revision 1.1

Intel order number G26942-003

Figure 30. Video Connector Pin-out

Note: Intel Corporation server boards support peripheral components and can contain a number

of high-density VLSI and power delivery components that need adequate airflow to cool. Intel’s

own chassis are designed and tested to meet the intended thermal requirements of these

components when the fully integrated system is used together. It is the responsibility of the

system integrator that chooses not to use Intel

developed server building blocks to consult

vendor datasheets and operating parameters to determine the amount of airflow required for

their specific application and environmental conditions. Intel Corporation cannot be held

responsible if components fail or the server board does not operate correctly when used outside

any of its published operating or non-operating limits.

8 GND

9 P5V

10 GND

11 NC

12 CRT_DDCDATA

13 CRT_HSYNC

14 CRT_VSYNC

15 CRT_DDCCLK
