Intel S2600CP Family User Manual

Intel
®
Server System P4000CP Accessories Intel
®
Server Board S2600CP and Server System P4000CP TPS
Revision 1.1
Intel order number G26942-003
162
Figure 64. Intel
®
RAID C600 Key
14.2 Intel
®
Remote Management Module 4 (Intel
®
RMM4)
Intel
®
Remote Management Model 4 (RMM4) includes two components, Intel
®
Remote
Management Module 4 Lite (RMM4 Lite) and Intel
®
Dedicated Server Management NIC (DMN).
RMM4 Lite is the key that can enable advance features of server onboard Integrated BMC.
DMN can provide a dedicated management LAN interface. This DMN is only for Integrated BMC
management communication and cannot be shared with OS.
Table 136. Intel
®
Remote Management Module 4 (Intel
®
RMM4)
Intel
®
Product
Code
Description Kit Contents Benefits
AXXRMM4LITE Intel
®
Remote Management Module 4
Lite
RMM4 Lite Activation Key Enables KVM and media
redirection by onboard
NIC
AXXRMM4 Intel
®
Remote Management Module 4 RMM4 Lite Activation Key
Dedicated NIC Port Module
Dedicated NIC for
management traffic, KVM
and media Redirection.
The RMM4 can be installed in Intel
®
Server System P4000CP at the board and chassis
locations as shown in the figure below.

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
