Intel

Server Board S2600CP and Server System P4000CP TPS Appendix E: POST Code Diagnostic LED Decoder

Revision 1.1

Intel order number G26942-003

197

Table 154. MRC Fatal Error Codes

Checkpoint

Diagnostic LED Decoder

Description

1 = LED On, 0 = LED Off

Upper Nibble Lower Nibble

MSB LSB

8h 4h 2h

1h 8h 4h

LED #7 #6 #5

#4 #3 #2

MRC Fatal Error Codes

E8h

1 1 1 0 1 0 0 0

No usable memory error

E9h

1 1 1 0 1 0 0 1

Memory is locked by Intel Trusted Execuiton Technology and is

inaccessible

EAh

1 1 1 0 1 0 1 0

DDR3 channel training error

EBh

1 1 1 0 1 0 1 1

Memory test failure

EDh

1 1 1 0 1 1 0 1

DIMM configuration population error

EFh

1 1 1 0 1 1 1 1

Indicates a CLTT table structure error
