Note: The four blue ports from SCU labeled as “SAS_4”~”SAS_7” are NOT functional by default
and is only enabled with the addition of an Intel
®
RAID C600 Upgrade Key option supporting 8
SAS/SATA ports.
The server board is capable of supporting additional chipset embedded SAS and RAID options
from the SCU controller when configured with one of several available Intel
®
RAID C600
Upgrade Keys. Upgrade keys install onto a 4-pin connector on the server board labeled as
“Storage Upgrade key”. The following table identifies available upgrade key options and their
supported features. The Intel
®
RAID C600 Upgrade Keys do NOT work on Intel
®
Server Board
S2600CP2J.
Table 8. Intel
®
RAID C600 Upgrade Key Options
Intel
®
RAID C600 Upgrade Key Options
(Intel Product Codes)
Key Color Description
Default – No option key installed N/A 4 Port SATA with Intel
®
ESRT RAID 0,1,10 and Intel
®
RSTe RAID 0,1,5,10
RKSATA4R5 Black
4 Port SATA with Intel
®
ESRT2 RAID 0,1, 5, 10 and
Intel
®
RSTe RAID 0,1,5,10
RKSATA8 Blue 8 Port SATA with Intel
®
ESRT2 RAID 0,1, 10 and
Intel
®
RSTe RAID 0,1,5,10
RKSATA8R5 White
8 Port SATA with Intel
®
ESRT2 RAID 0,1, 5, 10 and
Intel
®
RSTe RAID 0,1,5,10
RKSAS4 Green 4 Port SAS with Intel
®
ESRT2 RAID 0,1, 10 and Intel
®
RSTe RAID 0,1,10
RKSAS4R5 Yellow
4 Port SAS with Intel
®
ESRT2 RAID 0,1, 5, 10 and
Intel
®
RSTe RAID 0,1,10
RKSAS8 Orange 8 Port SAS with Intel
®
ESRT2 RAID 0,1, 10 and Intel
®
RSTe RAID 0,1,10
RKSAS8R5 Purple
8 Port SAS with Intel
®
ESRT2 RAID 0,1, 5, 10 and
Intel
®
RSTe RAID 0,1,10
Additional information for the on-board RAID features and functionality can be found in the Intel
®
RAID Software Users Guide (Intel Document Number D29305-015).
The storage ports from SCU can be configured with the two embedded software RAID options:
 Intel
®
Embedded Server RAID Technology 2 (ESRT2) based on LSI* MegaRAID SW
RAID technology supporting RAID levels 0, 1, and 10.
 Intel
®
Rapid Storage Technology (RSTe) supporting RAID levels 0, 1, 5, and 10.
4.3.20.1 Intel
®
Embedded Server RAID Technology 2 (ESRT2)
Features of the embedded software RAID option Intel
®
Embedded Server RAID Technology 2
(ESRT2) include the following:
 Based on LSI* MegaRAID Software Stack
 Software RAID with system providing memory and CPU utilization
 Supported RAID Levels – 0,1,5,10
o 4 and 8 Port SATA RAID 5 support provided with appropriate Intel
®
RAID C600
Upgrade Key

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
