Intel S2600CP Family User Manual

Appendix D: Platform Specific BMC Appendix Intel
®
Server Board S2600CP and Server System P4000CP TPS
Revision 1.1
Intel order number G26942-003
188
Appendix D: Platform Specific BMC Appendix
This is an addendum document to BMC core EPS. This document describes platform and
chassis specific information.
Product ID
Bytes 11:12 (product ID) of Get Device ID command response: 4Ah 00h
IPMI Channel ID Assignments
Below table provides the information of BMC channels’ assignments.
Table 143. IPMI Channel ID Assignments
Channel ID Interface Supports
Sessions
0 Primary IPMB No
1 LAN 1 Yes
2 LAN 2 Yes
3 LAN3
1
(Provided by the Intel
®
Dedicated Server Management NIC)
Yes
4 Reserved Yes
5 USB No
6 Secondary IPMB No
7 SMM No
8– 0Dh Reserved –
0Eh Self
2
–
0Fh SMS/Receive Message Queue No
Notes:
1. Optional HW supported by the server system.
2. Refers to the actual channel used to send the request.
ACPI S3 Sleep State Support
Not support.
Processor Support for Intel
®
Server Board S2600CP
 Intel
®
Xeon
®
processor E5-2600 product family up to 135 Watt
 Intel
®
Xeon
®
processor E5-2600 v2 product family up to 135 Watt
Supported Chassis
 Intel
®
Server Chassis P4208XXM (Fixed fans, fixed or redundant PSUs)
 Intel
®
Server Chassis P4308XXM (Fixed fans, fixed or redundant PSUs)
 Intel
®
Server Chassis P4208XXM (Redundant fans, redundant PSUs)
 Intel
®
Server Chassis P4308XXM (Redundant fans, redundant PSUs)
 Intel
®
Server Chassis P4216XXM (Redundant fans, redundant PSUs)

Intel S2600CP Family Specifications

General

CPU Socket Type	LGA 2011
Max CPU Count	2
Chipset	Intel C602
Memory Slots	16
Processor Support	Intel Xeon E5-2600/E5-2600 v2 series
Memory Support	DDR3
Network Interface	Gigabit Ethernet
Storage Controller	6 x SATA 3Gb/s, 2 x SATA 6Gb/s
RAID Support	RAID 0, 1, 5, 10
Form Factor	SSI EEB
USB Ports	2 USB 3.0
