Appendix C: BMC Sensor Tables Intel
®
Server Board S2600CP and Server System P4000CP TPS
Revision 1.1
Intel order number G26942-003
178
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Readi
ng Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm
Stand-
by
Fan Tachometer Sensors
(Chassis specific
sensor names)
30h–
3Fh
Chassis
and
Platform
Specific
Fan
04h
Threshold
01h
[l] [c,nc]
nc =
Degraded
c = Non-fatal
2
As
and
De
Analog R, T M -
Fan Present Sensors
(Fan x Present)
40h–
4Fh
Chassis
and
Platform
Specific
Fan
04h
Generic
08h
01 - Device inserted OK
As
and
De
-
Triggered
Offset
Auto
-
Power Supply 1 Status
(PS1 Status)
50h
Chassis-
specific
Power Supply
08h
Sensor
Specific
6Fh
00 - Presence OK
As
and
De
– Trig Offset A X
01 - Failure Degraded
02 – Predictive Failure Degraded
03 - A/C lost Degraded
06 – Configuration
error
OK
Power Supply 2 Status
(PS2 Status)
51h
Chassis-
specific
Power Supply
08h
Sensor
Specific
6Fh
00 - Presence OK
As
and
De
– Trig Offset A X
01 - Failure Degraded
02 – Predictive Failure Degraded
03 - A/C lost Degraded
06 – Configuration
error
OK
Power Supply 1
AC Power Input
(PS1 Power In)
54h
Chassis-
specific
Other Units
0Bh
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 2
AC Power Input
(PS2 Power In)
55h
Chassis-
specific
Other Units
0Bh
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 1 +12V % of
Maximum Current Output
(PS1 Curr Out %)
58h
Chassis-
specific
Current
03h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
