Intel S2600CP Family

Intel® Server Board S2600CP Overview Intel
®
Server Board S2600CP and Server System P4000CP TPS
8 Revision 1.1
Intel order number G26942-003
Callout Description Callout Description
A Slot 1, PCI Express* Gen3 AC System Fan 4 connector
B RMM4 LITE AD Internal eUSB SSD
C RMM4 NIC AE TPM
D Slot 2, PCI Express* Gen3 AF System Fan 2
E Slot 3, PCI Express* Gen3, open-ended AG System Fan 1
F Slot 4, PCI Express* Gen3 AH PMBus
G Battery AI Type-A USB
H
Slot 5, PCI Express* Gen3, from second
processor, open-ended
AJ LCP
I Slot 6, PCI Express* Gen3, support riser card AK HDD activity LED
J DIMM E1/E2/F1/F2 AL Main Power
