Intel® Server Boards S3200SH/S3210SH TPS Connectors and Jumper Blocks
88 Revision 1.8
Intel Order Number: E14960-009
6.5 I/O Connectors
6.5.1 VGA Connector
The following table details the pin-out of the VGA connector. This connector is stacked with the
COM1 connector.
Table 52. VGA Connector Pin-out (J8B1)
Signal Name Pin Signal Name Pin
RED B1 Fused VCC (+5V) B9
GREEN B2 GND B10
BLUE B3 NC B11
NC B4 DDCDAT B12
GND B5 HSY B13
GND B6 VSY B14
GND B7 DDCCLK B15
GND B8
Note: NC (No Connect)
6.5.2 NIC Connectors
The server board supports two NIC RJ-45 connectors. The following tables detail the pin-out of
the connectors.
Table 53. NIC2-Intel
®
82541PI (10/100/1000) Connector Pin-out (J5B1)
Signal Name Pin Signal Name Pin
P1V8_NIC_RC 1 NIC1_DMI0_DN 10
NIC2_DMI2_DN 2 NIC1_DMI0_DNP 11
NIC2_DMI2_DP 3 P1V8_NIC_RC 12
NIC1_DMI2_DP 4 NIC2_LINK1000_N 13
NIC1_DMI2_DN 5 NIC2_LINK100_N 14
P1V8_NIC_RC 6 NIC2_ACT_LED_N 15
P1V8_NIC_RC 7 NIC2_LINK_UP_N 16
NIC1_DMI3_DP 8 GND MP1
NIC1_DMI3_DN 9 GND MP2
