System BIOS Intel® Server Boards S3200SH/S3210SH TPS
Revision 1.8 47
Intel Order Number: E14960-009
4.3.2 Server Platform Setup Screens
The following sections describe the screens available for the configuration of a server platform.
The tables in these sections describe the contents of each screen. These tables follow these
guidelines:
The BIOS Setup screens display the text and values in the Setup Item, Options, and
Help columns in the tables.
Bold text in the Options column of the tables indicates default values. These values do
not display in bold on the setup screen. The bold text in this document serves as a
reference point.
The Comments column provides additional information where it may be helpful. This
information does not display in the BIOS Setup screens.
Information in the screen shots enclosed in brackets (< >) indicates text that varies,
depending on the option(s) installed. For example, <Current Date> is replaced by the
actual current date.
Information enclosed in square brackets ([ ]) in the tables indicates areas where the user
must type in text instead of selecting from a list of provided options.
4.3.2.1 Main Screen
Unless an error occurred, the Main screen is the first screen that displays during the BIOS
Setup. If an error occurred, the Error Manager screen displays instead.
