Intel® Server Boards S3200SH/S3210SH TPS System BIOS
64 Revision 1.8
Intel Order Number: E14960-009
Server Management
Console Redirection
Console Redirection
Disabled / Serial A / Serial B
Flow Control
None / RTS/CTS
Baud Rate
9.6k / 19.2k / 38.4k / 57.6k / 115.2k
Terminal Type
PC-ANSI / VT100 / VT100+ / VT-UTF8
Legacy OS Redirection
Disabled / Enabled
Figure 23. Setup Utility — Console Redirection Screen Display
Table 30. Setup Utility — Console Redirection Configuration Fields
Setup Item Options Help Text
Console Redirection
Disabled
Serial A
Serial B
Console redirection allows a serial port to be used for
server management tasks.
[Disabled] - No console redirection.
[Serial Port A] - Configure serial port A for console
redirection.
[Serial Port B] - Configure serial port B for console
redirection.
Enabling this option will disable display of the Quiet
Boot logo screen during POST.
Flow Control
None
RTS/CTS
Flow control is the handshake protocol.
Setting must match the remote terminal application.
[None] - Configure for no flow control.
[RTS/CTS] - Configure for hardware flow control.
Baud Rate 9600
19.2K
38.4K
57.6K
115.2K
Serial port transmission speed. Setting must match
the remote terminal application.
Terminal Type PC-ANSI
VT100
VT100+
VT-UTF8
Character formatting used for console redirection.
Setting must match the remote terminal application.
Legacy OS
Redirection
Disabled
Enabled
This option will enable legacy OS redirection (i.e.,
DOS) on serial port. If it is enabled the associated
serial port will be hidden from the legacy OS.
