Connectors and Jumper Blocks Intel® Server Boards S3200SH/S3210SH TPS
Revision 1.8 91
Intel Order Number: E14960-009
6.5.6 Keyboard and Mouse Connector
Two PS/2 ports are provided for a keyboard and a mouse. The following table details the pin-out
of the PS/2 connectors.
Table 58. Keyboard and Mouse PS/2 Connectors Pin-out (J9A1)
PS/2 Connectors Pin Signal Name
K1 RKBDATA
K2 NC
K3 GND
K4 P5V_KB_MS
K5 RKBCLK
Keyboard
K6 NC
M1 MSEDATA
M2 NC
M3 GND
M4 P5V_KB_MS
M5 RMSCLK
Mouse
M6 NC
6.5.7 USB Connector
The following table provides the pin-out for the dual external USB connectors. This connector is
stacked with an RJ-45 (connected to NIC1 LAN signals).
Table 59. USB Connectors Pin-out (J5B1)
Pin Signal Name
U1 P5V_USB_BP_MJ
U2 USB_BACK5_R_DN
U3 USB_BACK5_R_DP
U4 GND
U5 P5V_USB_BP_MJ
U6 USB_BACK4_R_DN
U7 USB_BACK4_R_DP
U8 GND
