Server Board Overview Intel® Server Boards S3200SH/S3210SH TPS
2 Revision 1.8
Intel Order Number: E14960-009
2. Server Board Overview
The Intel
®
Server Boards S3210SHLX, S3200SHL, S3200SHV, and S3210SHLC are monolithic
printed circuit boards (PCBs) with features designed to support the entry server market.
2.1 Server Board Feature Set
All board SKUs are based on the Intel
®
3200/3210 Chipset
Supports processors in LGA775 package
800/1066/1333 MHz Front Side Bus (FSB) speed
Four DDR2 667/800MHz unbuffered DIMM memory sockets with or without ECC
Supports the Intel
®
ICH9R I/O Controller, interfaced with MCH via DMI
LX board SKU supports the following I/O slots:
o One PCI Express* x16 connector to be used as a x16 link from chipset (If a VGA
adapter is inserted into this slot, the VGA card will only work at PCI Express* x1
speed; this is a chipset limitation.)
o One PCI Express* x8 connector to be used as a PCI Express* x8 link from the
chipset
o Two PCI-X 133 MHz, 64-bit connectors
o One PCI 5 V, 32-bit, 33 MHz connector
LC board SKU supports following I/O slots:
o One PCI Express* x16 connector to be used as a x16 link from chipset (If a VGA
adapter is inserted into this slot, the VGA card only works at PCI Express* x1
speed; this is a chipset limitation.)
o One PCI Express* x8 connector to be used as a PCI Express* x8 link from the
chipset
o One PCI Express* x8 connector routed to PCI Express* x4 bus from the ICH9R
o Two PCI 5 V, 32-bit, 33 MHz connectors
L and V board SKUs support the following I/O slots:
o One PCI Express* x16 connector to be used as a x8 link from chipset (If a VGA
adapter is inserted into this slot, the VGA card only works at PCI Express* x1
speed; this is a chipset limitation.)
o One PCI Express* x8 connector routed to the PCI Express* x4 bus from the
ICH9R
o Two PCI 5 V, 32-bit, 33 MHz connectors
On-board ServerEngines* LLC Pilot II controller (Integrated BMC) supports the following
functions:
o Integrated 2-D video controller on PCI Express* x1
o Super I/O on LPC
o Baseboard Management Controller (BMC) based on ARM946E-S
