System BIOS Intel® Server Boards S3200SH/S3210SH TPS
Revision 1.8 59
Intel Order Number: E14960-009
Table 26. Setup Utility — USB Controller Configuration Screen Fields
Setup Item Options Help Text Comments
Detected USB
Devices
Information only: Shows number of
connected USB devices
USB Controller
Enabled
Disabled
[Enabled] - All onboard USB controllers will be turned on
and accessible by the OS.
[Disabled] - All onboard USB controllers will be turned off
and inaccessible by the OS.
Legacy USB
Support
Enabled
Disabled
Auto
PS/2 emulation for USB keyboard and USB mouse
devices.
[Auto] - Legacy USB support will be enabled if a USB
device is attached.
Device Reset
timeout
10 sec
20 sec
30 sec
40 sec
USB Mass storage device Start Unit command timeout.
Storage Emulation Header for next line.
One line for each
mass storage
device in system
Auto
Floppy
Forced FDD
Hard Disk
CD-ROM
[Auto] - USB devices less than 530MB will be emulated as
floppy.
[Forced FDD] - HDD formatted drive will be emulated as
FDD (e.g., ZIP drive).
This setup screen can show a
maximum of eight devices on this
screen. If more than eight devices
are installed in the system, the “USB
Devices Enabled” displays the
correct count, but only the first eight
devices can display here.
USB 2.0
controller
Enabled
Disabled
Onboard USB ports will be enabled to support USB 2.0
mode.
Contact your OS vendor regarding OS support of this
feature.
4.3.2.2.6 PCI Screen
The PCI Screen provides fields to configure PCI add-in cards, the onboard NIC controllers, and
video options.
To access this screen from the Main screen, select Advanced |
PCI.
