System BIOS Intel® Server Boards S3200SH/S3210SH TPS
Revision 1.8 57
Intel Order Number: E14960-009
Advanced
Serial Port Configuration
Serial A Enable Enabled/Disabled
Address 3F8h / 2F8h / 3E8h / 2E8h
IRQ 3 or 4
Serial B Enable Enabled/Disabled
Address 3F8h / 2F8h / 3E8h / 2E8h
IRQ 3 or 4
Figure 18. Setup Utility — Serial Port Configuration Screen Display
Table 25. Setup Utility — Serial Ports Configuration Screen Fields
Setup Item Options Help Text
Serial A
Enable
Enabled
Disabled
Enable or Disable Serial port A.
Address
3F8h
2F8h
3E8h
2E8h
Select Serial port A base I/O address.
IRQ 3
4
Select Serial port A base interrupt request (IRQ)
line.
Serial B
Enable
Enabled
Disabled
Enable or Disable Serial port B.
Address 3F8h
2F8h
3E8h
2E8h
Select Serial port B base I/O address.
IRQ
3
4
Select Serial port B base interrupt request (IRQ)
line.
4.3.2.2.5 USB Configuration Screen
The USB Configuration screen provides fields to configure the USB controller options.
To access this screen from the Main screen, select Advanced |
USB Configuration.
