Intel® Server Boards S3200SH/S3210SH TPS Connectors and Jumper Blocks
90 Revision 1.8
Intel Order Number: E14960-009
Signal Name Pin Signal Name Pin
GND 13 FDR0# 14
GND 15 FDMTR1# 16
Unused 17 FDDIR 18
GND 19 FDSTEP# 20
GND 21 FDWDATA# 22
GND 23 FDWGATE# 24
GND 25 FDTRK0# 26
Unused 27 FLWP# 28
GND 29 FRDATA# 30
GND 31 FHDSEL# 32
GND 33 FDSKCHG# 34
6.5.5 Serial Port Connectors
The server board provides one serial port. A standard, external DB9 serial connector is located
on the back edge of the server board to supply a serial interface. This connector is stacked with
VGA connector (J8A1).
Table 57. External DB9 Serial A Port Pin-out (J8B1)
Signal Name Pin Signal Name Pin
DCD-P T1 DSR-P T6
RXD-P T2 RTS-P T7
TXD-P T3 CTS-P T8
DTR-P T4 RI-P T9
GND T5
