Intel® Server Boards S3200SH/S3210SH TPS System BIOS
60 Revision 1.8
Intel Order Number: E14960-009
Advanced
PCI Configuration
Dual Monitor Video Enabled / Disabled
Onboard NIC ROM Enabled / Disabled
NIC 1 MAC Address <MAC #>
NIC 2 MAC Address <MAC #>
Figure 20. Setup Utility — PCI Configuration Screen Display
Table 27. Setup Utility — PCI Configuration Screen Fields
Setup Item Options Help Text Comments
Dual Monitor Video Enabled
Disabled
Both the onboard video controller and an add-in
video adapter will be enabled for system video.
The onboard video controller will be the primary
video device.
Onboard NIC ROM
Enabled
Disabled
Load the embedded option ROM for the onboard
network controllers.
Warning: If [Disabled] is selected, NIC1 and NIC2
cannot be used to boot or wake the system.
NIC 1 MAC Address No entry
allowed
Information only. 12 hex
digits of the MAC address.
NIC 2 MAC Address No entry
allowed
Information only. 12 hex
digits of the MAC address.
4.3.2.3 Security Screen
The Security screen provides fields to enable and set the user and administrative password and
to lock out the front panel buttons so they cannot be used.
To access this screen from the Main screen, select the Security option.
