Intel® Server Boards S3200SH/S3210SH TPS System BIOS
56 Revision 1.8
Intel Order Number: E14960-009
Table 24. Setup Utility — ATA Controller Configuration Screen Fields
Setup Item Options Help Text Comments
Onboard SATA
Controller
Enabled
Disabled
Onboard Serial ATA (SATA)
controller.
When enabled, the SATA
controller can be configured in
RAID Mode.
Configure SATA as
SATA
RAID
IDE
[AHCI] – The SATA drives will be
set to work as independent
SATA drives
[RAID] - SATA controller will be
in RAID mode and the Intel
®
RAID for Serial ATA option ROM
will execute.
[IDE] – The SATA drives will be
set to work as independent
SATA drives
When RAID is selected, no SATA
drive information is displayed.
SATA Port 0 < Not Installed / Drive
information>
Information only: Unavailable
when RAID Mode is enabled.
SATA Port 1 < Not Installed / Drive
information>
Information only: This field is
unavailable when RAID Mode is
enabled.
SATA Port 2 < Not Installed / Drive
information>
Information only: This field is
unavailable when RAID Mode is
enabled.
SATA Port 3 < Not Installed / Drive
information>
Information only: This field is
unavailable when RAID Mode is
enabled.
SATA Port 4 < Not Installed / Drive
information>
Information only: This field is
only available when AHCI Mode
is enabled.
SATA Port 5 < Not Installed / Drive
information>
Information only: This field is
only available when AHCI Mode
is enabled.
4.3.2.2.4 Serial Ports Screen
The Serial Ports screen provides fields to configure the Serial A [COM 1] and Serial B [COM2].
To access this screen from the Main screen, select Advanced |
Serial Port.
