System BIOS Intel® Server Boards S3200SH/S3210SH TPS
Revision 1.8 51
Intel Order Number: E14960-009
Table 21. Setup Utility — Advanced Screen Display Fields
Setup Item Options Help Text
Processor Configuration View/Configure processor information and settings.
Memory Configuration View/Configure memory information and settings.
SATA Controller Configuration View/Configure SATA Controller information and
settings.
Serial Port Configuration View/Configure serial port information and settings.
USB Configuration View/Configure USB information and settings.
PCI Configuration View/Configure PCI information and settings.
4.3.2.2.1 Processor Screen
The Processor screen provides a place for the user to view the processor core frequency,
system bus frequency, and enable or disable several processor options. The user can also
select an option to view information about a specific processor.
To access this screen from the Main screen, select Advanced |
Processor.
Advanced
Processor Configuration
Processor Family <String from Processor>
Core Frequency <Current Processor Frequency>
Maximum Frequency <Maximum Processor Speed Possible>
System Bus Frequency <Current FSB Frequency>
L2 Cache Size <Size of the cache>
Processor Stepping <Stepping # of this processor>
CPUID Register <CPUID>
Enhanced Intel
®
SpeedStep Tech Enabled / Disabled
Core Multi-processing Enabled / Disabled
Intel
®
Virtualization Technology Enabled/ Disabled
Execute Disable Bit Enabled / Disabled
Figure 15. Setup Utility — Processor Configuration Screen Display
