Connectors and Jumper Blocks Intel® Server Boards S3200SH/S3210SH TPS
Revision 1.8 87
Intel Order Number: E14960-009
6.2 Intel
®
Riser Card for L SKU
The Intel
®
Server Board S3200SH-L has a PCI Express* x16 to PCI Express* x16 riser card.
This riser card is designed to be populated with PCI Express* x16 slot on the Intel
®
Server
Board S3200SH-L. The physical layout to the PCI Express* x16 slot on the riser card is PCI
Express* x8.
This riser card is designed for populating the Intel
®
Server Board S3200SH-L into the Intel
®
Server Chassis SR1530.
6.3 SMBus Connector
Table 50. SMBus Connector Pin-out (J1E1)
Pin Signal Name Description
1 SMB_DAT_5V_BP Data Line
2 GND GROUND
3 SMB_CLK_5V_BP Clock Line
4 TP_BP_I2C_HRD_4 Test Point
6.4 Front Panel Connector
A standard SSI 24-pin header is provided to support a system front panel. The header contains
reset, NMI, power control buttons, and LED indicators. The following table details the pin-out of
this header.
Table 51. Front Panel 24-Pin Header Pin-out (J1K2)
Signal Name Pin Signal Name Pin
FP_PWR_LED_P1 1 P3V3_STBY 2
KEY 3 P5V_STBY 4
FP_GPIO_GRN_BLNK_HDR 5 FP_ID_LED_N 6
P3V3 7 TP_SSI_PIN8 8
LED_HD_N 9 TP_SSI_PIN10 10
FP_SW_ON_HDR_N 11 FP_NIC1_ACT_LED_R_N 12
GND 13 NIC1_LINK_1_N 14
FP_RST_FPHDR_N 15 TP_SSI_PIN16 16
GND 17 TP_SSI_PIN18 18
FP_ID_BTN_N 19 FP_Intruder_HDR_N 20
TP_FM_ONE_WIRE_TEMP_SENSOR 21 FP_NIC2_ACT_LED_R_N 22
TP_SSI_PIN23 23 NIC2_LINK_UP_N 24
