Intel® Server Boards S3200SH/S3210SH TPS Server Board Overview
Revision 1.8 3
Intel Order Number: E14960-009
Winbond* PC8374L super I/O chip interfaced to the Intel
®
ICH9R through LPC supports
the following:
o PS/2 keyboard/mouse
o Floppy disk drive (FDD)
o Six SATA II connectors
Five USB 2.0 ports: two ports on USB/LAN combo connectors at the rear of the server
board, two ports via on-board headers, and one port on an internal vertical connector
Two Gigabit (Gbit) Ethernet devices interfaced to the Intel
®
ICH9R to support two rear
panel RJ-45 connectors with integrated magnetics; one is through PCI Express* x1, the
other one is through PCI32
ACPI (Advanced Configuration and Power Interface) power management
System monitoring (temperature, voltage, and fans)
VRD11 for processor
The server board supports the following feature set:
Processor and FSB support
o Supports Intel
®
Xeon
®
processor 3000 series, Intel
®
Xeon
®
processor 3100
series, Intel
®
Xeon
®
processor 3200 series, and Intel
®
Xeon
®
processor 3300
series.
o Supports Intel
®
dual-core technology
o Supports Intel
®
Extended Memory System 64 Technology (Intel
®
EM64T)
Intel
®
3200/3210 Chipset components
o Intel
®
3200/3210 Memory Controller Hub (MCH)
o Intel
®
ICH9R I/O Controller
o Intel
®
6702 PXH-V PCI-X Hub (LX board SKU only)
Memory System
o Four DIMM sockets supporting DDR2 667/800MHz DIMMs
o Data bandwidth per channel of 4.2 GB/s or 8.4 GB/s in dual channel when using
DDR2 667 MHz
o Support for up to two DDR2 channels for a total of four DIMMs (two DIMMs /
channel) providing up to 8 GB max memory capacity
o Support for 512 MB, 1 GB, and 2 GB DRAM modules
Notes: 1. The server board does not support DDR2-533 DIMMs.
2. The server board does not support 256 MB DIMMs.
I/O Subsystem
Clock
o CK-505 compliant System Clock Generator
