Intel® Server Boards S3200SH/S3210SH TPS System BIOS
74 Revision 1.8
Intel Order Number: E14960-009
Setup Item Help Text Comments
Load Default Values Load factory default values for all BIOS Setup
Utility options.
The [F9] key can also be used.
Prompts user for confirmation.
Save as User Default
Values
Save current BIOS Setup Utility values as
custom user default values. If needed, the user
default values can be restored via the Load
User Default Values option below.
Note: Clearing CMOS or NVRAM will cause the
user default values to be reset to the factory
default values.
Prompts user for confirmation.
Load User Default
Values
Load user default values. Prompts user for confirmation.
4.3.2.9.1 Fan Speed Control Methodology
Intel
®
Server Boards S3200SH and S3210SH have an integrated BMC (Baseboard
Management Controller), which provides advanced fan speed control features compared to
previous platforms. The integrated BMC FW and FRUSDR provide HW monitoring, fan speed
control, and system management features.
Intel released FRUSDRs will contain the fan speed control support for Intel
®
server chassis by
default. The supported chassis are:
Intel
®
Server Chassis SR1530
Intel
®
Entry Server Chassis SC5299-UP
For any third party non-Intel chassis, if a customer wants to implement similar fan speed control
to the system fans attached inside the third party chassis, they must edit the master.cfg file
included in the FRUSDR update package. The FRUSDR manages the system fans to work at
the speed the customer inputs.
Intel will publish a third party chassis fan speed control white paper to guide customers on how
to edit the master.cfg file to have fan speed control functions for the third party chassis. Without
doing so, the third party chassis fan speed cannot be controlled as the FRUSDR does not
recognize the fans, and does not know what speed the fans should operate at under which
environment temperatures.
