Intermec EasyCoder PF4i User Manual

Chapter A — Technical Data
106 EasyCoder PF4i User’s Guide (IPL Version)
Printing
Print Technique Direct Thermal and Thermal
Tr a n s f e r
Printhead Resolution 8 dots/mm (203 dpi)
Print Speed (variable) 100 to 200 mm/sec ( ± 4 to 8 in./
sec.)
Print Width (max) 104 mm (4.095 in.) or 832 dots
Print Length (max) 32767 dots = 409.5 cm
(161.25 in.) See Note 1
Media Width (min/max)
Standard Edge Guides
25 to 114.3mm (1 to 4.5 in.)
Media Width (min/max)
Quick-Load Guides
40/80 to 114.3 mm
(1.57/3.15 to 4.5 inches)
Media Roll Diameter (max) 213 mm (8.38 in.)
Media Roll Core Diameter 38 to 40 mm (1.5 in.)
Ribbon Width (min/max) 55 to 110 mm (2.17 to 4.33 in.)
Ribbon Roll Diameter (outer),
max.
65 mm (2.56 in.) with 240-300 m
(787-985 feet) of ribbon, depending
on ribbon thickness.
Ribbon Roll Core Diameter
(inner)
25 mm (1.00 inches)
Print Directions 4
Modes of Operation
Tear-Off (Straight-through) Yes
Cut-Off Option With cutter installed
Peel-Off (Self-strip) Option With rewinder installed
Firmware
Operating System IPL v2.20
Smooth Fonts 13 scalable + 21 simulated bitmap
Built-in bar code symbologies 38

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
