Intermec EasyCoder PF4i User Manual

Chapter A — Technical Data
EasyCoder PF4i User’s Guide (IPL Version) 107
Physical Measurements
Dimensions (W × L × H)
With long side door
244 x 397 x 178 mm
(9.61 x 15.63 x 7.00 inches)
Dimensions (W × L × H)
With paper cutter installed
253 x 447 x 178 mm
(9.96 x17.60 x 7.00 inches)
Dimensions (W × L × H)
With 8-inch Megatop installed
244 x 471 x 225 mm
(9.61 x 18.54 x 8.86 inches
Weight (excluding media) 7 to 8 kg (15.5 to 17.7 pounds)
Ambient Operating Temperature +5°C to +40°C (+41°F to +104°F)
Humidity 20 to 80% non-condensing
Electronics
Microprocessor 32 bit RISC
On-board Flash SIMMs 2 sockets for 4MB or 8MB each
Standard 1x 4MB
On-board SDRAM SIMM 1 socket for 8MB or 16MB
Standard 8MB
Power Supply
AC Voltage 90 to 265 VAC, 45 to 65 Hz
PFC Regulation IEC 61000-3-2
Power Consumption Minimum 15W; Peak 300W
Sensors
Label Gap/Black Mark/Out of Media Yes
Five fixed positions.
Printhead Lifted Yes
Ribbon End/Ribbon Low Yes
Thermal transfer model only.
Controls
Indicator Lamps 3
Display 2 × 16 character LCD with background light

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
