Intermec EasyCoder PF4i User Manual

Chapter A — Technical Data
108 EasyCoder PF4i User’s Guide (IPL Version)
Note 1: The maximum print length is also restricted by the
amount of free SDRAM memory.
Note 2: Depending on model, the printer may be delivered with
one of three types of doors.
Keyboard 7 keys membrane-switch type
Feed/Pause button 1
Beeper Yes
Data Interfaces
Serial 1 × RS-232
Connection for Optional
Interface Boards
1 + 1 1 for EasyLAN, 1 for
EEEE 1284
Memory Card Adapter 1 Firmware upgrade only.
Accessories and Options
Thick Media Printhead 170-220 μm (6.6 to 8.7 mm)
Integral Self-strip Unit with Liner
Take up
For peel-off operation
Rotating Media Supply Hub Replaces supply post
3-inch Adapter for Media Supply Hub
Cutter
Short Side Door See Note 2
Long Side Door See Note 2
Long Side Door with 8-inch Megatop See Note 2
Label Taken Sensor Option
RS-232 Cable Option
Parallel Interface Cable
Parallel Interface Board Option IEEE 1284
EasyLAN Ethernet Interface
EasyLAN Wireless Interface
CompactFlash Cards 8MB - 1 GB
Controls

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
