Intermec PC43t User Manual

Chapter 5 — Troubleshoot the Printer
98 PC23 and PC43 Desktop Printer User Manual
About Printer System Information
Look in the System Information tab in the printer web pages for useful
information and statistics on the printer hardware and firmware. This
information can be useful when you contact Intermec Product
Support for assistance or troubleshooting.
System Information Tab in Printer Web Pages
View Printer Statistics
If your printer is connected to an Ethernet or Wi-Fi network, you can
view printer statistics in the printer web page.
1 On your PC, open a browser.
2 In the Location or Address bar, type the printer IP address and
press Enter. The printer web page appears.
3 Click the System Information tab.
Note: The printer must be connected to an Ethernet or wireless
network to view system information in the printer web page.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
