Intermec PC43t User Manual

Chapter 6 — Maintain the Printer
PC23 and PC43 Desktop Printer User Manual 119
6 Connect the ribbon cable to the new printhead.
7 Slide the printhead into the holders in the print mechanism.
8 Press the printhead onto the locator pins in the mechanism.
9 Tilt the printhead up into the printer lid and press it into place.
When the printhead is in the correct position, the printhead latches
snap into place on the sides of the printhead.
10 For a thermal transfer printer, install the ribbon.
11 Close the printer lid until it snaps shut.
12 Print a test label.
Clean the Platen Roller
Follow this procedure to remove, clean, and replace the platen roller as
part of standard maintenance for the printer. Intermec recommends
that you check the platen roller for debris and clean it each time you
replace media.
1 Turn the printer off and disconnect the power cord.
2 Pull one or both of the printer latches toward the front of the
printer and lift the printer lid.
3 Remove the installed media.
Warning: Do not touch the printhead surface area.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
