Intermec PC43t User Manual

Chapter 2 — Set Up the Printer
PC23 and PC43 Desktop Printer User Manual 61
Print a Test Label in Start Up Mode
You can print a test label when you first turn on the printer.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 Connect the printer to power and turn on the printer.
3 On the icon printer, when the last two LEDs are lit (Maintenance
and Bluetooth), press and hold
until the test label starts to
print.
On the LCD printer, when the status bar appears, press and hold
until the Media Calibration Wizard appears. Select and
press to print a label with the current print settings.
Print a Test Label in Idle Mode
You can print a test label when the printer is in Idle mode.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 On the icon printer, press and hold until the test label starts to
print.
On the LCD printer, press and hold until the Media
Calibration Wizard appears. To print a label with the current print
settings, select
and press .
Print a Test Label from the Main Menu
If you have an LCD printer, you can print a test label from the Main
Menu.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 From the Ready screen, press .

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
