Intermec PC43t User Manual

Chapter 1 — About the Printers
20 PC23 and PC43 Desktop Printer User Manual
The printer command language is saved to memory, and remains set to
ESim/ZSim until you change this setting.
How to Set the Printer Command Language
You can use one of these methods to change the printer command
language:
• Printer web page
• Main Menu
• Print button
• PrintSet 5. For more information, see the PrintSet 5 online help.
Set the Command Language from the Printer Web Page
To set the command language from the printer web page, you need to
turn on the printer and connect to your Ethernet or Wi-Fi network.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 On your PC, open a browser.
3 In the Location or Address bar, type the printer IP address and
press Enter. The printer web page appears.
4 Click Login. The Login page appears.
5 Type your Username and Password and click Login. The default
username is itadmin and the default password is pass.
6 Click the Configure tab.
7 Click System Settings > General.
8 Select a different printer command language from the Command
Language list, and then click Save.
9 Click the Services tab.
10 Click Reboot Printer, and then click Reboot. The printer restarts
in the command language you selected.
Note: If you are using an icon printer without an Ethernet or Wi-Fi
network, you must use the Print button or PrintSet 5 to set the printer
command language.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
