Intermec PC43t User Manual

Chapter 1 — About the Printers
12 PC23 and PC43 Desktop Printer User Manual
About the Main Menu
In the printer Ready screen, press to view the Main Menu.
Press and to highlight Main Menu items, and then press to
select that item:
• Select Programs to see a list of programs installed on the printer.
This list includes utility programs provided by Intermec as part of
the printer firmware, and programs you have installed on the
printer.
The Programs item appears in the Main Menu only if the printer
is using Fingerprint or Direct Protocol as the command language.
• Select Settings to view and change printer settings.
• Select Tools to print test labels, manage a connected USB storage
device, restore printer default settings, or save and load printer
profiles.
• Select Wizards to see a list of wizards that help you configure
printing or communication settings, or calibrate the media
sensors.
Main Menu
Programs
Settings
Tools
Wizards
Note: The printer cannot print while the Main Menu is onscreen. You
need to exit the Main Menu and return to the Ready screen to begin
printing.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
