Intermec PC43t User Manual

Chapter 1 — About the Printers
PC23 and PC43 Desktop Printer User Manual 29
Battery Base LEDs
When the battery base is connected to AC power, the LEDs indicate the
battery charge status.
When the battery base is not connected to AC power, you can press the
Charge Level button to briefly turn on the LEDs and see the battery
charge level.
LEDs: Battery Base Connected to AC Power
LEDs Battery Charge Status
95% to 100%
76% to 94%
51% to 75%
26% to 50%
0% to 25%
Battery out of charging temperature
range.
Battery error.
LEDs: Battery Base Not Connected to AC Power
LEDs Battery Charge Level
Battery is 76% to 100% charged.
Battery is 51% to 75% charged.
Battery is 26% to 50% charged.
Battery is 11% to 25% charged.

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
