Intermec PC43t User Manual

Chapter 3 — Connect the Printer
72 PC23 and PC43 Desktop Printer User Manual
Connect the Printer to an Ethernet Network
If your printer has an Ethernet module, you can connect it to your
wired network. For help installing this accessory, see the PC23d,
PC43d, and PC43t Ethernet Module Installation Instructions.
1 Connect an Ethernet cable to the Ethernet port on the rear of the
printer and to your network.
2 Get the IP address for your printer:
• For an LCD printer, from the Main Menu select Settings >
Communications > Ethernet and find the IP address.
• For an icon printer, press and hold until the test label with
the IP address starts to print.
3 Configure the necessary Ethernet settings:
• For an LCD printer, from the Main Menu select Settings >
Communications > Ethernet.
• For an icon printer, configure the Ethernet settings through
PrintSet 5 or the printer web page.
&UIFSOFUQPSU

Intermec PC43t Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	106 mm
Internal memory	128 MB
Built-in barcodes	AZTECCODE, Code 49, Data Matrix, EAN128, EAN13, EAN8, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code
Page description languages	IPL, XML, ZPL
Display	LCD
Product color	Black
Display resolution	480 x 234 pixels
Wi-Fi	-
USB port	Yes
Optional connectivity	Bluetooth, Ethernet, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Maximum label width	118 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	281 mm
Width	210 mm
Height	182 mm
Weight	2700 g
